Outdoor double-bay 4-door cabinet (1500 W × 750 D × 1430 H) finished in UVRPE Karaka Green powder coat.
Featuring overlapping front and back doors, 19″ mounting rails (28 RU + 6 RU), 100 mm heavy-duty HDG plinth for battery support, swing-handle padlock, louvered doors with filter foam, inbuilt shelving, and side insulation for secure, weather-protected equipment housing.
| Width | 1500 |
|---|---|
| Depth | 750 |
| Height | 1430 |
| Rack Units | |
| Number of Bays | |
| Number of Doors | |
| Door Specs | |
| Locking System | |
| Cabinet Family | |
| Standard Features |
The Double Bay 4-Door Cabinet (1500 W × 750 D × 1430 H) is a heavy-duty outdoor enclosure designed to provide secure, weather-protected housing for critical equipment. The cabinet is finished in UVRPE Karaka Green powder coat, delivering long-term corrosion resistance and durability in harsh outdoor environments.
This cabinet features a double-bay, four-door configuration with overlapping front and back doors to improve sealing and protection. It is supplied with two pairs of 19″ mounting rails at 28 RU and two pairs of 19″ mounting rails at 6 RU, offering flexible mounting options for a wide range of equipment.
A 100 mm HDG steel plinth, complete with front, back, and side plinth covers, provides a strong base and supports battery installation. For security, the cabinet includes a swing-handle padlock. Louvers on the doors with filter foam allow controlled airflow while reducing dust ingress.
Inside, the cabinet is fitted with three inbuilt battery shelves and one inbuilt top shelf, along with side insulation to assist with maintaining stable internal conditions. This enclosure is suitable for telecommunications, data, energy, and industrial applications where robust construction, environmental protection, and secure access are essential.
