Triple-bay outdoor cabinet (1500W x 350D x 1450H mm) featuring three front doors with CWL three-point flush locking systems, filtered ventilation louvres, and twin ceiling-mounted 230V fans with thermostat control.
Includes internal compartment dividers, four-side insulation, a fibreglass roof, removable cable gland plates, and drained floor pans.
Designed for electrical, telecommunications and infrastructure equipment installations.
See our real-world deployment with Watercare’s Bulk-Supply Monitoring Network:
https://www.cable-ways.co.nz/watercare-bulk-supply-monitoring/
| Width (mm) | 1500 |
|---|---|
| Depth (mm) | 350 |
| Height (mm) | 1450 |
| Rack Units | |
| Number of Bays | |
| Number of Doors | |
| Door Specs | |
| Locking System | |
| Roof | Fibreglass – RF Transparent Roof |
| Cabinet Family | |
| Standard Features |
The Cable Ways Triple Bay 3 Door Cabinet is a robust outdoor enclosure designed to house communications, monitoring, telemetry and control equipment across three separate equipment bays.
The cabinet features three front doors with 3-point flush-front locking, providing secure and convenient access to each section. Internal left and right panel dividers provide separation between equipment areas for an organised installation.
Thermal management combines insulation and active ventilation. The cabinet is insulated on four sides and fitted with a fibreglass roof. The left front door and right side panel incorporate louvres, with filter foam fitted to the left door. The dry side is equipped with twin ceiling-mounted 230V fans with thermostats to assist with temperature management.
Cable entry and drainage are provided through floor pans, including a left floor pan fitted with two removable gland plates.
Case-Study Example
Over 300 units operate within the Watercare Bulk-Supply Monitoring system, supporting real-time data collection, remote communications, and long-term field reliability.
View the case study here:
https://www.cable-ways.co.nz/watercare-bulk-supply-monitoring/
Custom Options
Colour, insulation packages, specialised cooling, internal shelving, cable-management systems, mounting plates, power-distribution modules, and project-specific integrations are available.
