Double-bay 2-door outdoor cabinet (1500W × 900D × 1432H) designed for power distribution and infrastructure applications.
Features forced convection with fan, naturally vented louvre doors with filter foam, and 5-sided insulation.
Includes flexible internal configuration with optional LED lighting, door security switch, fan kit, 316 stainless steel power chassis, and battery holder brackets (pair).
| Width | 1500 |
|---|---|
| Depth | 900 |
| Height | 1432 |
| Rack Units | |
| Number of Bays | |
| Number of Doors | |
| Door Specs | |
| Locking System | |
| Cabinet Family | |
| Standard Features |
Double-bay 2-door outdoor cabinet (1500W × 900D × 1432H) engineered for electrical, telecommunications, and infrastructure applications requiring robust construction, flexible internal layout, and reliable thermal performance. The enclosure is designed to support a wide range of equipment configurations, including power distribution, control systems, and communications equipment.
The cabinet incorporates a combination of naturally vented door louvres with filter foam and forced convection with fan, providing effective airflow management. This dual approach supports heat dissipation while limiting dust ingress, making it suitable for outdoor environments with varying thermal loads.
Constructed with durability in mind, the enclosure includes 5-sided insulation, improving thermal stability and protecting internal equipment from external temperature fluctuations. The cabinet is finished in a UV-resistant powder coat, supporting long-term performance in harsh environmental conditions.
The internal layout is designed for flexibility and scalability. The cabinet supports optional 19″ EIA mounting rails, allowing integration of rack-mounted equipment across both bays. A polypropylene base with twin access panels and central gland plates enables organised cable entry and management.
Additional configurable features include:
For installation flexibility, the cabinet can be mounted on an optional 100 mm aluminium plinth, improving cable access, drainage, and site adaptability.
This cabinet provides a modular, durable, and thermally managed enclosure solution, suitable for applications across transport, energy, water, and telecommunications sectors where reliability, flexibility, and long service life are critical.
